Crane end beam system for clean room

| Crane end beam system for clean room

An end beam system for a crane for a clean room, comprising an end beam beam body, a flat rail, a rail bearing beam, a motor and a dust collecting box; a dust collecting box is arranged under the moto

CATEGORY:

News

CREATED:

Mar 31, 2022

An end beam system for a crane for a clean room, comprising an end beam beam body, a flat rail, a rail bearing beam, a motor and a dust collecting box; a dust collecting box is arranged under the motor arranged on the side of the end beam beam body; the end beam beam body A flat rail is arranged below the rail, and the flat rail is arranged on the upper surface of the upper flange plate of the rail-bearing beam; the wheel is a flat wheel and a flat wheel walks on the flat rail. The utility model carries out nickel plating treatment on the wheels and changes the original grooved wheels into existing flat wheels, which are used in conjunction with stainless steel flat rails. The parts with high frequency are treated with nickel plating to effectively reduce the generation of dust; the parts with friction are treated with nickel plating; the utility model adopts a simple and efficient structure to greatly prevent the generation of dust and spread to the external environment, The whole set of equipment runs smoothly, has low noise, is easy to install and maintain, and is safe and efficient to use.

An end beam system for a crane for a clean room, which is characterized in that it comprises an end beam beam body, a flat rail, a rail bearing beam, a motor, and a dust collecting box; A flat rail is arranged below the beam body of the end beam, and the flat rail is arranged on the upper surface of the upper flange plate of the rail-bearing beam.
