Non-Driven DRSA 112 Wheel Block System

DRS 112 Wheel Block is used to move heavy loads safely and efficiently. Designed to support the weight of the crane and facilitate its movement along runways, and contribute to the stability and control of the heavy loads.

Non driven wheel block, also known as engaged wheel or passive wheel, is a wheel block that does not receive power or torque from the motor.

Normally, non-driven wheel blocks are connected to the driven wheel through a drivetrain system, such as a transmission, and provide the necessary traction to move forward or backward. The primary function of non-driven wheels is to provide stability, steering control, and support to the vehicle. They allow the vehicle to roll smoothly and maintain traction during cornering, braking, and other maneuvers.

Travel wheel types:

A: Travel wheel blocks with flanges on both sides

B: Wheels without any flanges

D: Wheel with flange on one side

E: Wheels without flange, with larger diameter

S: Special travel wheel

F: Hydropur, without flange, with larger diameter

C: Polyamide without flange, with larger diameter

In addition, we can provide wheel core coating service, polyurethane coated rubber wheel at a lower price, can safely bear 2 tons.

Wheel block systems help a lot in crane, trolley and systems building as well as in custom applications and special constructions. For example,

1. Transverse conveyor

2. Distribuion carriage for pallets in store used in the beverages industry

3. distribution carriage for aluminum bars

KUNFENG CRANES offer a comprehensive range of products in the industry. Includes drives with solutions for a wide variety of requirements, such as starting and stopping motions, positioning, travel or variable speed drives. Contact us to get a quick quotation!
