Manual Hoist Double Beam Suspension Crane

Manual hoist double beam suspension crane is a kind of lifting equipment with simple structure and easy operation. The double beam suspension frame is used to support and hang the manual hoist to lift and move objects. A manual hoist is a device that uses manual operation to raise and lower hooks and move goods. This kind of crane is usually used in factories, warehouses, docks and other places, and can effectively improve the efficiency and safety of lifting operations.

Structure and composition

  1. Hook: used for lifting goods and can be replaced as needed.

  2. Wire rope: connects the hook and manual hoist and is the main load-bearing component.

  3. Manual hoist: The goods are lifted and lowered by manually turning the chain or pulling the hand chain.

  4. Double beams: Two parallel or staggered steel beams support the entire crane structure, and the movement of goods between the double beams is achieved through pulleys and other components.

  5. Outriggers: Used to support the weight of the crane and can be adjusted as needed.

  6. Control system: used to control the lifting and movement of goods, which can be adjusted as needed.

Structural features

  1. The entire crane structure is simple and clear, easy to manufacture and maintain.

  2. The lifting and moving of goods is realized through manual hoist, which is simple and convenient to operate.

  3. Compared with other types of cranes, the manufacturing cost of manual hoist double-girder suspension cranes is lower.

  4. It can be adjusted as needed to adapt to various usage scenarios.

  5. The design is reasonable, safe and reliable, and can ensure the safety of operators and the integrity of goods.

Scenes to be used

  1. In the factory workshop, it can be used to hoist various equipment, materials and semi-finished products to improve production efficiency.

  2. On construction sites, it can be used to hoist construction materials, equipment and personnel to improve construction efficiency.

  3. In the warehouse, it can be used for hoisting goods, handling and sorting, etc. to improve warehousing efficiency.

  4. In the logistics center, it can be used for loading, unloading, handling and sorting of goods to improve logistics efficiency.
