Fully Automatic Load Turning Device

Fully automatic load turning device is a device used to turn workpieces or products to different angles. It can complete the flipping or tilting of objects without manual intervention, and is widely used in metallurgy, stamping, sheet metal, mould, papermaking, refrigeration and other industries.

According to the maximum turning angle, the automatic load turning device can be divided into 90° load turning device and 180° load turning device; according to its realized performance, it can be divided into steel coil load turning device, mold load turning device and plate load turning device. According to its structure type, it can be divided into frame type load turning device, belt type load turning device and chain type load turning device.

The working principle of the automatic load turning device is to use the motor, hydraulic system or pneumatic system to drive the turning mechanism, and turn the workpiece from one direction to another through transmission methods such as gears, racks, belts, and chains. Different types of fully automatic load turning devices have different turning mechanisms, such as frame type, belt type, chain type, etc. The performance of the automatic load turning device mainly depends on its turning angle, turning speed, turning stability, turning accuracy, adaptability and safety.

Advantages of automatic load turning machine:

  ● It can adapt to the turning requirements of goods of different specifications and shapes, and realize the operation goal of converting goods from horizontal to vertical or from vertical to horizontal;

  ● It can improve work efficiency, save manpower, and reduce labor intensity and safety risks of operators;

  ● It can be well connected and matched with the production process to realize the three-dimensional process of cargo transportation, without the characteristics of high conveying rate such as labor and overhead cranes;

  ● It can lift, move, and flip items during the conveying process, and can combine auxiliary devices to realize the handling of items at right angles, parallel, up and down, etc.;

  ● Simple structure, low cost, convenient maintenance, economical and energy-saving;

  ● Standardization, serialization, high degree of generalization, easy to assemble to form different production lines, and does not require special civil engineering foundation.

Precautions for installation of automatic load turning device:

  ● Pay attention to safety during installation and wear safety protective equipment.

  ● Make sure that the position and size of the hoisting holes of the equipment meet the design requirements, and pre-weld the hoisting holes.

  ● The fasteners used must meet the design requirements, and safety should be paid attention to during the fastening process.

  ● After the equipment is installed, it needs to be temporarily fixed and adjusted, and a test run should be carried out.
